Suitable for interior wall paint and putty spraying in public buildings, including factories, hotels, schools, and hospitals.
One robot works with two workers: one for operation, one for putty scrapping.
Finishing quality is superior to manual work; putty spraying coverage rate exceeds 80%; first coat of putty spraying reaches 1000-1200㎡/day, second coat reaches 1600-2000㎡/day.
Five Core Advantages
Ultra-Compact Design
Industry-first ultra-thin body (single side < 800mm), equipped with an omnidirectional mobility platform, delivering zero-turn-radius maneuverability. Effortlessly navigates narrow corridors in internationally standardized building spaces.
01
Intelligent Adjustable Support System
Innovative Telescopic outrigger design: stays compact in retracted mode for efficient passage through tight spaces; when deployed, forms a four-point stable base to ensure safety during high-altitude spraying.
02
Long-Lasting Power Solution
Up to 8 hours of continuous operation on a single charge—sufficient for full-day high-intensity tasks.
03
Smart & High-Power Putty Mixer
The dedicated high-efficiency putty mixer adopts a "one-grind, dual-filter" process to ensure putty material is smooth and free of particles.
04
Triple-Stage Filtration Technology
Built-in patented progressive filtration system performs three-stage purification before spraying, effectively eliminating impurities for a clean and consistent spray finish.
Six Key Features
Exceptional Spraying Quality
Delivers smooth and consistent coat. The first coat of putty is applied at 1.2–1.5 mm thickness, and the second coat at 0.6–0.9 mm—surpassing manual work quality and outperforming comparable products in the industry.
Full Scene Coverage
With the industry’s most compact body (single side < 800 mm) and a self-developed omnidirectional chassis, the robot easily enters narrow spaces and adapts to complex construction environments.
Combined with a 6-DOF robotic arm, intelligent lift system, and AI-powered algorithms, it accurately simulates human motions, enabling seamless automated spraying on walls, ceilings, inside/outside corners, beams, and more—ensuring complete, dead-zone-free coverage.
High-Efficiency Smart Operation
Spraying efficiency is outstanding:
First coat: 1,000–1,200 m²/day
Second coat: 1,600–2,000 m²/day
Multiple Safety Mechanisms
Equipped with both active and passive safety systems, the robot performs real-time monitoring throughout operation to ensure zero safety incidents. Since entering the market, it has maintained a 100% accident-free record.
Simplified Smart Operation
Tablet-based one-click control with an intuitive visual UI —no programming skills required. Ordinary workers can independently run the robot after basic training. Built-in standardized spraying presets enable quick job start and eliminate manual parameter tuning errors, greatly lowering the usage threshold.
Ultra-Low Failure Rate with Worry-Free Support
The robot delivers stable and reliable performance, backed by a professional technical team that ensures fast response and comprehensive support throughout the product’s lifecycle.
Suitable for interior wall paint and putty spraying in residential buildings, apartments, hotels, and office buildings, the house painting robot streamlines the process with consistent quality.
One robot works with two workers: one for operation, one for putty scrapping.
Suitable for interior wall paint and putty spraying in residential buildings, apartments, hotels, and office buildings, the house painting robot streamlines the process with consistent quality.
One robot works with two workers: one for operation, one for putty scrapping.
Finishing quality superior to manual work; putty spraying coverage rate exceeds 80%; first coat of putty spraying reaches 500-600㎡/day, second coat reaches 800-1000㎡/day.
Four Core Advantages
World's First Mobile Spraying Technology
Legend Robot’s pioneering mobile spraying technology, applied through its advanced construction painting robot, enables simultaneous movement and spraying, boosting efficiency by 1.5 to 2 times compared to traditional stop-and-spray methods.
01
Most Compact Design in the Industry
With the most compact body—measuring under 800mm in both length and width—the robot meets global construction site access standards. Featuring a proprietary omnidirectional chassis with zero turning radius, it easily navigates narrow spaces for 100% site accessibility.
02
Proprietary Dedicated Putty Mixer
Equipped with a dedicated putty mixer, the system ensures fine and consistent putty texture through one grinding and two-stage filtration, significantly reducing the robot's failure rate. It can prepare 60L of putty within 5 minutes—enough to supply two robots simultaneously—delivering outstanding production efficiency.
03
Built-in Filtration System
The robot features an integrated putty filtration system. Before spraying, the putty undergoes a three-stage filtration process, which greatly reduces the risk of clogging and mechanical failure.
04
Six Key Features
Superior Spraying Quality
The first coat of putty is sprayed at a thickness of 1.2–1.5 mm, and the second coat at 0.6–0.9 mm. Spraying thickness is precisely controlled, ensuring high flatness and a smooth, even finish.
Sufficient Coverage Rate
With the industry’s most compact body and a proprietary omnidirectional chassis featuring zero turning radius, gap-crossing, ramp climbing, and obstacle negotiation, the robot easily navigates narrow and complex spaces for broad site accessibility.
Equipped with a 6-DOF robotic arm, lifting mechanism, and mature spraying algorithms, it flexibly adjusts spray angles to simulate human motion—delivering fully automatic, blind-spot-free spraying of walls, ceilings, and corners.
High Spraying Efficiency
Powered by Legend Robot’s pioneering mobile spraying technology, our reliable system surpasses the efficiency limits of traditional stationary methods, enabling smooth and highly efficient construction.
The first coat of putty——500–600 m² per day,
The second coat of putty——800–1000 m² per day.
Proven Safety
Since deployment, no safety incidents have occurred. The robot features dual active and passive safety systems, providing comprehensive protection for worry-free operation.
Easy to Use
One-touch tablet control with an intuitive visual UI requires no programming skills. Ordinary workers can independently run the construction painting robot after basic training. Built-in standardized spraying programs enable quick start-up, eliminating complex manual adjustments and errors.
Low Failure Rate
Thanks to the combined effect of the robot’s built-in filtration system and the dedicated mixer, the risk of failure is significantly reduced, ensuring stable and reliable performance. Legend Robot also offers a professional after-sales support that provides prompt response and reliable service.
Suitable for interior wall painting in residential buildings, apartments, hotels, and office buildings.
Full automation: one worker can automate three robots, with workers only responsible for refilling paint and relocating the robots.
Finishing quality surpasses manual work, with painting coverage exceeding 95% and daily efficiency reaching 2400–3000㎡. These autonomous wall painting robots ensure consistent results across large areas while minimizing labor.
Three Core Advantages
Compact Body
Compact Body
The smallest body in the industry (single side < 800mm), this automatic wall painting robot features an omnidirectional chassis with zero turning radius, allowing easy access to narrow building spaces. Its compact design delivers high adaptability and consistent wall coverage, reducing manual labor while maintaining precision. Ideal for residential buildings, apartments, hotels, and offices, it ensures professional finishes with efficiency and safety.
01
Telescopic outrigger— Flexible and Reliable
Telescopic outrigger— Flexible and Reliable
Telescopic support legs: compact and portable when retracted, easily passing through narrow spaces and convenient for transport; stable and secure when extended, ensuring safe and steady operation during extra-high spraying tasks.
02
Long-Lasting Battery Life
Long-Lasting Battery Life
Up to 12 hours of continuous operation.
Six Key Features
Superior Spraying Quality
Superior Spraying Quality
Delivers uniform and high-quality spraying. A single coat achieves a thickness of 70μm ± 5μm — outperforming manual work and similar products in the market.
High Coverage Capability
High Coverage Capability
With a compact body and omnidirectional chassis, the autonomous wall painting robot is able to enter complex construction environments and narrow spaces, ensuring excellent scene adaptability.
Equipped with a 6-DOF robotic arm, lift mechanism, and AI-powered algorithms, this automatic wall painting machine simulates all human spraying motions, enabling fully automated spraying of walls, ceilings, corners, beams, and other feature surfaces.
High Spraying Efficiency
High Spraying Efficiency
The robot achieves an exceptional spraying efficiency of 2,400–3,000 m² per day.
High Safety
High Safety
Since deployment, there have been zero safety incidents. The robot is equipped with both active and passive safety systems, offering dual-layer protection and peace of mind during operation.
Easy to Use
Easy to Use
One-click control via tablet with an intuitive, visualized UI—no programming skills required. Ordinary workers can run the robot independently after basic training.
Built-in standardized spraying programs allow quick job startup, eliminating the complexity and errors of manual parameter tuning.
Low Failure Rate
Low Failure Rate
With an average of just 0.33 failures per unit per month—only one-fifth of the industry average—the robot is highly stable and dependable.
Legend Robot provides a professional after-sales service team for timely support and reliable maintenance.
