DI Series continuous horizontal vacuum belt filter is a high level automatic new –type filter.this type of filter use cloth or filter screen as medium, make the slurry be placed horizontally on the medium, use slurry gravity and vacuum suction to reach solid-liquid separation. It applicable in many kinds of concentration material, because ... moreDI Horizontal Vacuum Tray Belt Filter https://www.heshengfilters.com/products/di-horizontal-vacuum-tray-belt-filter/
DI Series continuous horizontal vacuum belt filter is a high level automatic new –type filter.this type of filter use cloth or filter screen as medium, make the slurry be placed horizontally on the medium, use slurry gravity and vacuum suction to reach solid-liquid separation. It applicable in many kinds of concentration material, because of the high filtering efficiency, it priority used in many industries.
Features of DI Horizontal Vacuum Tray Belt Filte
● Feeding, filtering, cake washing, cake discharging, filter cloth washing and redirection can be finished continuously and automatically, so it has high level automation.
● It can wash cake with several times clean water and filtrate,the filtrate(mother liquor) and washed liquor can be collected separately.
● It can filter quickly in a thin layer for the sludge with high viscosity and bad filtration character and has high adaptability.
● It’s flexible to assemble by its modular structure, convenient for transportation, installation and maintenance.
● It’s convenient to remote and local control by PLC control.
WASHING DEVICE
Use process water to spray washing cloth and equipped with vacuum sealing box to ensure the using site clean. The spray nozzle uses the American atomization company product to fully guarantee the washing effect.
CAKE WASHING PROCESS
Adopt the overflow washing and drip spray washing devices, according to the materialand the process requirement to use clean water direct washing or the filtrate indirect washing,which can wash the cake thoroughly.
REDERECTION DEVICE
Adoptcylinderor air-bag to push the redirection roller move a certain angle to adjust the cloth automatically and ensure the cloth running normally.
CONTROL SYSTEM
Adopts remoteand local alternately control, convenient for the operation workand unmannedoperation.
The ceramic disc filter is a kind of equipment which use the vacuum negative pressure and the capillarity of ceramic plate to realize solid-liquid separation.Extract air inside of the ceramic plate to make the pressure difference with external, under the negative pressure, the solids in the slurry tank will be absorbed on the ceramic plate surface... moreCF Ceramic Disc Vacuum Filter https://www.heshengfilters.com/products/cf-ceramic-disc-vacuum-filter/
The ceramic disc filter is a kind of equipment which use the vacuum negative pressure and the capillarity of ceramic plate to realize solid-liquid separation.Extract air inside of the ceramic plate to make the pressure difference with external, under the negative pressure, the solids in the slurry tank will be absorbed on the ceramic plate surface. And the filtrate will be flow from the outside to inside of ceramic plate with negative pressure difference and the hydrophilicity of ceramic plate, so that to reach the purpose of the solid-liquid separation.
Operation Principle
The ceramic plate immersed in the slurry tank, and the material cake layer formed on its surface under vacuum negative pressure and adsorbed by the plate capillary. The liquid passes through the inside of the plate and pipes to the vacuum tank and discharge out.The cake on the plates running by main roller to drying area, and continues to dehydrate under vacuum function. Then running to cake discharging area (without vacuum) to discharge the cake by ceramic scraper.After discharging, the ceramic plate running to the back washing area, the process water or compressed air will be enters to the ceramic plate inside by the back washing pipes, and washing the ceramic plate holes from inside to outside.After working for one shift, the ceramic plate should be washed by ultrasonic waves and combined with low concentration acid to ensure its efficiency.
Specifications of CF Ceramic Disc Vacuum Filter
It is widely used in concentrate and tailings dewatering of mining, ferrous metals, non-ferrous metals, rare metals, non-metallic and environmental protection sewage sludge dewatering and waste acid treatment, etc.
Features of CF Ceramic Disc Vacuum Filter
● Low power consumption, low operation cost (low vacuum loss).
● low cake moisture, low solids content in filtrate and can be reused.
● High automation, compact structure, small space occupied, and easy installation and maintenance.
