Angle Globe Valve is designed for precise flow regulation and efficient shut-off in piping systems where a 90-degree change in flow direction is required. Combining the functions of a globe valve and an elbow, it minimizes pipeline fittings while reducing pressure loss and installation space.
Specification of Angle Globe Valve
Angle Globe Valve is designed for precise flow regulation and efficient shut-off in piping systems where a 90-degree change in flow direction is required. Combining the functions of a globe valve and an elbow, it minimizes pipeline fittings while reducing pressure loss and installation space.
Specification of Angle Globe Valve
Specification Item Details/Values
Size Range 1/2"–12" (DN15–DN300)
Pressure Rating Class 150-Class 300 / PN6–PN40
Body Materials ASTM A216 WCB, A105, A217 WC6/WC9, A351 CF8, CF8M, CF3, CF3M, Duplex Stainless Steel, Alloy Steel
Bonnet Type Bolted Bonnet, Pressure Seal Bonnet
Disc Type Plug Disc, Regulating Disc, Hard-Faced Disc
Stem Rising Stem, Precision Machined
Seat Material Integral Seat, Renewable Seat Ring, Stellite Overlay (Optional)
End Connection Flanged, Butt Weld, Socket Weld, Threaded
Face-to-Face Standard ASME B16.10 / Manufacturer Standard
Flange Standard ASME B16.5, ASME B16.47, EN 1092-1
Butt Weld Standard ASME B16.25
Inspection & Testing API 598, ISO 5208
Design Standard API 623, BS 1873, ASME B16.34
Fire Safe Design Available upon request
Operating Temperature -160°C to 595°C (Material Dependent)
Applicable Medium Water, Steam, Oil, Gas, Chemical Fluids, Thermal Oil
Operation Handwheel, Gear Operator, Pneumatic Actuator, Electric Actuator
Optional Features Locking Device, Position Indicator, Extended Bonnet, Cryogenic Service, Special Trim Materials
Applications Oil & Gas, Petrochemical, Power Plants, Refineries, LNG, Chemical Processing, Industrial Pipelines
Features of Angle Globe Valve
Integrated 90° Flow Path Design
Combines a globe valve and a 90-degree elbow into one unit, eliminating the need for an additional pipe fitting and reducing installation complexity.
Reduced Pipeline Space Requirements
The angle body design enables compact piping layouts, making it ideal for installations with limited space or directional changes.
Lower Pressure Loss Than Elbow + Globe Valve Assemblies
By integrating the change in flow direction within the valve body, the Angle Globe Valve minimizes turbulence and pressure drop compared with separate elbow and globe valve combinations.
Ideal for Bottom Drain and Blowdown Service
Commonly used for boiler blowdown, drain lines, sampling systems, and vessel discharge applications where fluid must change direction while maintaining precise shut-off.
Efficient Drainage Performance
The angled outlet promotes smoother media discharge, helping to reduce fluid retention and improve drainage efficiency after shutdown.
Fewer Leak Points
Replacing a separate elbow and valve with a single integrated body reduces flange or welded joints, lowering the risk of external leakage and simplifying maintenance.
Improved Resistance to Flow-Induced Erosion
The optimized angle-flow configuration directs high-velocity media more effectively, reducing localized erosion in demanding service conditions.
Suitable for High-Velocity Steam and Liquid Applications
Designed to handle high-pressure steam, condensate, boiler feedwater, and other process fluids where directional flow control is required.
Simplified Piping Installation
Fewer piping components reduce installation time, material costs, and overall system weight while improving piping reliability.
Optimized for Precise Flow Control at Direction Changes
Maintains the excellent throttling performance of a globe valve while efficiently accommodating a 90-degree change in flow direction, making it ideal for process control applications.
