Nakoda Steel Industry is a manufacturer of Drawn Over Mandrel DOM Tubes Tubing, Our Manufacturing unit based in India, China, and Malaysia. Dom tubes manufacturing superior grade of steel like ASTM A513. DOM is a preferred choice for a wide range of mechanical tubing applications because it combines the advantages of closely controlled dimensions (OD/ID/Wall), superior concentricity, and a uniform wall thickness. In addition, DOM offers smooth OD and ID surfaces, high mechanical properties, and excellent machinability.
DOM tubing is created from flat sheets of raw material, rolled on a weld mill to produce a mother hollow. A number of material options are available, including AISI class 1008, 1010, 1020, and 1026. The material is subjected to a normalizing heat treatment to produce a suitable tube for cold working.
STOCKED SIZE RANGE:
• 0.250” to 2.000” O.D. from 0.028” to 0.120” Wall Thickness
We will Supply tubes from Malaysia, India & China.
DOM – ERW Tubing Capabilities: |
|
Product Name | Drawn Over Mandrel (DOM) Electric Resistance Welded (ERW) Tubing |
Tube Specifications / Standards | ASTM A513 Type 5 ASTM A513 Type 6 |
Diameter (OD) | 0.375″ to 8.000″ |
Wall Thickness | 0.035″ to 0.500″ |
Steel Grades & Alloys | 1008 – ST 37-2 1010 – ST 52.3 1020 – STKM 11a 1026 – STKM 12b 4130 – STKM 13c Many More Grades Available as Requested |
Heat Treatments | Stress Relieving Full Anneal Normalizing |
Grade Designation | Chemical Composition Limits, % | |||
Carbon | Manganese | Phosphorus, max | Sulfur, max | |
1010 | 0.05-0.15 | 0.30-0.60 | 0.035 | 0.035 |
1015 | 0.10-0.20 | 0.30-0.60 | 0.035 | 0.035 |
1020 | 0.15-0.25 | 0.30-0.60 | 0.035 | 0.035 |
1026 | 0.22-0.28 | 0.60-0.90 | 0.035 | 0.035 |
ASTM A513 Chemical Composition
Hardness Limits and Tensile Properties for Round Tubing |
|||||
Yield Strength, Ksi (MPa), min | Ultimate Strength, ksi (MPa), min | Elongation in 2 in. or 50 mm. % min | RB min | RB max | |
As-Welded Tubing | |||||
1008 | 30 (207) | 42 (290) | 15 | 50 | |
1010 | 32 (221) | 45 (310) | 15 | 55 | |
1015 | 35 (241) | 48 (331) | 15 | 58 | |
1020 | 38 (262) | 52 (359) | 12 | 62 | |
1026 | 45 (310) | 62 (427) | 12 | 68 | |
Normalized Tubing | |||||
1008 | 23 (159) | 38 (262) | 30 | 65 | |
1010 | 25 (172) | 40 (276) | 30 | 65 | |
1015 | 30 (207) | 45 (310) | 30 | 70 | |
1020 | 35 (241) | 50 (345) | 25 | 75 | |
1026 | 40 (276) | 60 (414) | 25 | 85 | |
Sink-Drawn Tubing | |||||
1008 | 38 (262) | 38 (262) | 8 | 65 | |
1010 | 40 (276) | 40 (276) | 8 | 65 | |
1015 | 45 (310) | 45 (310) | 8 | 67 | |
1020 | 50 (345) | 50 (345) | 8 | 70 | |
1026 | 55 (379) | 55 (379) | 7 | 77 | |
Mandrel-Drawn Tubing | |||||
1008 | 50 (345) | 60 (414) | 5 | 73 | |
1010 | 50 (345) | 60 (414) | 5 | 73 | |
1015 | 55 (379) | 65 (448) | 5 | 77 | |
1020 | 60 (414) | 70 (483) | 5 | 80 | |
1026 | 70 (483) | 80 (552) | 5 | 85 | |
Mandrel-Drawn Stress-Relieved Tubing | |||||
1008 | 45 (310) | 45 (310) | 55 (379) | 12 | 68 |
1010 | 45 (310) | 45 (310) | 55 (379) | 12 | 68 |
1015 | 50 (345) | 50 (345) | 60 (414) | 12 | 72 |
1020 | 55 (379) | 55 (379) | 65 (448) | 10 | 75 |
1026 | 65 (448) | 65 (448) | 75 (517) | 10 | 80 |
