Putting tempered glass in heat soaked furnace heating again,The heating stage begins at the ambient temperature of all the glasses and ends at the moment when the surface temperature of the last piece of glass reaches 280 ℃. The temperature inside the furnace may exceed 320 ℃.
Heat soaked glass spontaneous rate is lower than 0.1-0.3‰, much lower than tempered glass 3‰.
Putting tempered glass in heat soaked furnace heating again,The heating stage begins at the ambient temperature of all the glasses and ends at the moment when the surface temperature of the last piece of glass reaches 280 ℃. The temperature inside the furnace may exceed 320 ℃.
Heat soaked glass spontaneous rate is lower than 0.1-0.3‰, much lower than tempered glass 3‰.
Lanjing has the heat soaked furnace doing glass processing.
Features of Heat Soaked Glass
Reduced Risk of Spontaneous Breakage: Spontaneous breakage rate drop to below 0.1-0.3‰.
Enhanced Safety: By removing the possibility of spontaneous breakage, heat soaked glass offers a significant safety improvement.
Heat Soaked Glass Applications
Construction field：Mainly used for glass curtain walls, glass doors and windows, glass handrails, glass partitions, etc
Home appliance field：Commonly used in equipment such as televisions, microwaves, ovens, refrigerators, washing machines, etc
Automotive field：Mainly use for components such as car windows, rearview mirrors, and headlights.
FTO (Fluorine doped Tin Oxide) glass is a transparent conductive glass composed of a special glass substrate and a layer of FTO film. FTO film is a wide bandgap semiconductor material composed of tin oxide (SnO2) and fluorine (F). The doping of fluorine element can significantly improve the conductivity of tin oxide.
FTO (Fluorine doped Tin Oxide) glass is a transparent conductive glass composed of a special glass substrate and a layer of FTO film. FTO film is a wide bandgap semiconductor material composed of tin oxide (SnO2) and fluorine (F). The doping of fluorine element can significantly improve the conductivity of tin oxide.
Descriptions of FTO Conductive Glass
FTO is an n-type semiconductor material, therefore it has extremely high conductivity, reaching over 10 ^ 4 S/cm
Lanjing supply different thickness of FTO glass with different resistance.
Glass Dimension Information:
Stock sheet panel can be various, 2140x3300mm, 2250x3210mm ,1830x2440mm, 1830x2200mm and any other customized.
Processed size: FTO glass can be tempered ,the size following client’s cutting list.
Descriptions of FTO Conductive Glass
FTO Glass Features
Transparency
FTO glass has excellent optical transparency, especially in the visible and near ultraviolet light regions, which is crucial for photovoltaic and optoelectronic display applications.
Conductivity
FTO glass has high electrical conductivity, which makes it widely used in electronic devices and circuits.
Stability
FTO glass has good chemical and thermal stability, which allows it to maintain its properties under various environmental conditions.
Easy to obtain
The production process of FTO glass is relatively simple and the cost is low, which makes it suitable for large-scale commercial applications.
FTO Glas Application
FTO glass is widely used in：
photovoltaic devices, such as solar cells, dye-sensitized solar cells, organic photovoltaic cells, thin-film solar cells.
FTO Glas Application
Optoelectronic Display Devices (such as liquid crystal displays).
In the Field of Touch Screens
FTO glass can serve as a conductive layer for touch screens, utilizing its excellent conductivity and transparency to provide a high-quality touch experience
Used for Automobiles
Front windshield and side window glass,By changing the thickness and resistance of FTO glass, automatic adjustment of indoor lighting can be achieved.
Home Appliances
FTO glass made into insulated glass used for refrigerator doors, oven doors and the display cabinet.
EVA is Ethylene-vinyl Acetate laminated glass, offers several features and benefits compared to traditional polyvinyl butyral (PVB) laminated glass.
EVA laminated glass is not low-temperature laminated, it’s resistant to low temperatures but not high temperature.
EVA Laminated Glass Advantage
High transparency and adhesion: High transparency supply a better visual. its high adhesion can be applied to various interfaces, including glass, metal, and plastic.
Good durability and weather resistance: EVA laminated material can resist environmental factors such as high temperature, moisture, and ultraviolet radiation, and has good durability.
Easy to store: Stored at room temperature, the adhesion of EVA is not affected by humidity and water absorbing film.
Low melting point, easy to flow, suitable for various glass laminating processes, such as patterned glass, tempered glass, curved glass, etc
Curved Glass is made by heating the original float glass sheet to a softening temperature, bending the glass into shape, then rapidly and uniformly cooling it with specialized equipment.
Curved glass can be made to laminated glass and insulated glass.
Curved Glass is made by heating the original float glass sheet to a softening temperature, bending the glass into shape, then rapidly and uniformly cooling it with specialized equipment.
Curved glass can be made to laminated glass and insulated glass.
Curved Glass Has Two Types
Tempered Curved Glass
It’s made in the tempered furnace, heating to the softening temperature, bending the glass into shape. It has the same features with tempered glass.
Tempered curved glass has the limited size on the radius and height.
Tempered curved glass Capability:
Hot Bend Glass
Hot bent glass is not tempered, is a curved glass made by heating and softening flat glass in a mold, then annealing it. It can made to various shape.
The differences between tempered curved glass and hot bend glass.
Combining traditional blinds with insulating glass not only saves space and inconvenience, but also achieves the insulation and shading performance. The blind inside the insulated glass can be lifted and flipped,it’s easy to operate.
Combining traditional blinds with insulating glass not only saves space and inconvenience, but also achieves the insulation and shading performance. The blind inside the insulated glass can be lifted and flipped,it’s easy to operate.
Blind Insulated Glass Features
1. Sunshade Properties
The shading coefficient of the built-in louvered insulating glass ranges from Sc=0.18 to Sc=0.90. When the louvers are in a vertical state, the shading coefficient Sc=0.18; When the blinds are in a horizontal state, the shading coefficient Sc=0.83.
2. Energy efficiency
Blind insulated glass are made of high-quality and aluminum louvers The U value can reach below 1.8, while the ordinary hollow glass is 3.0; the monolithic glass is generally 5.8.
3. Prevent Dust, oil fume, and pollution
The biggest advantage of blind insulated glass is the ability to prevent dust, oil fumes, and pollution. The blinds do not need to be cleaned to save your time.
4. Fire resistance
Blind insulated glass are not susceptible to open flames and do not release thick smoke in large fires. The double-layer tempered glass with aluminum louvers also has the function of blocking flame transmission, effectively reducing the probability of fire occurrence, and is a good fireproof product.
5. Soundproofing performance
Normal insulated glass can generally reduce indoor noise from RW-86 decibels to RW-45 decibels, while hollow louvers can reduce indoor noise to below RW-30 decibels, ensuring perfect sound insulation effect.
Blind Insulated Glass Features
Blind Insulated Glass Types
Manual control
The magnetic block operation handle is used to control the closing device and lifting device to operate the louvers inside the insulated glass, such as lifting and flipping. The angle of the louvers can be adjusted to control the light and radiant heat entering the room, meeting the needs of insulation and indoor lighting.
Blind Insulated Glass Types
Electric control
Using a 24V high silent motor to drive the lifting and angle adjustment of the blinds, wall button switch control, wireless remote control, voice control, and APP control can be achieved, eliminating the need for people to manually control the opening and closing of the blinds by walking to the window Elevating and lowering has great convenience and a good experience.
Blind Insulated Glass Types
Optoelectronic intelligent control
The technical principle is to use "solar photovoltaic panels" to convert solar energy into electrical energy and continuously supply power to the "lithium battery receiver", thereby controlling the transmission system inside the glass cavity, achieving the functions of opening, closing, and dimming the blinds.
